When semi-metallic friction material is too aggressive, NB240-GG premium high performance brakes are the proven solution.
NB240-GG Premium High Performance Brakes
Description
NB240-GG premium high performance brakes boast a high-friction, organic asbestos-free formula that provides superior stopping power. They’re ideal material for ABS equipped equipment, as performance and wear characteristics have been extensively evaluated in millions of miles of practical use by fleets.
These high performance brake blocks meet the inertia dynamometer requirement of the FMVSS 121 brake standard at a 26,000 lb. GAWR when using an AL factor of 180 type (30 air chamber and a 6″ slack adjuster).
When semi-metallic material is too aggressive, NB240-GG premium high performance brakes are the answer.
Application
Recommended for use on trucks, tractors, and trailers in all applications including general cargo, stop and go urban driving, bus, grain, liquid hauling, dump trucks and lowboys. Also designed for hydraulic cam brakes and air operated steel axles.
Gogan Hardness
30 GC
Nondestructive method of measuring a lining’s compressibility. Used as a quality control check of the consistency of formulation and processing of brake lining (SAE J379a).
Specific Gravity
1.98
Nondestructive test used as a quality control check of the consistency of formulation and processing of brake lining (SAE J380).
Tensile Strength
1700 PSI
Method of evaluating physical strength of brake lining (ASTM D952). Force required to break a sample 1.0 x 1.0 inch.
Temp Range
1000 °F
Procedure
Typical Inertia Dynamometer Plot Test Parameters – FMVSS 121 Brake Standard
- Brake – 16.5″ x 7″ Meritor S-Cam
- AL Factor – 180
- Axle Load – 25,000 lbs.
- Rolling Radius – 20.7″
- Drum Weight – 120 lbs.
Retardation Force
Minimum Required Retardation
Temperature (F)
Pressure
This NeoBrake lining complies with the 2025 Zero Copper requirement.
